Features:
1. High -resistant wear
2. Time tolerance
3. High and low temperature
4. Light resistance
5. Weldable
Scope of application:
For car interior skin skin.
PVC performance data:
|
Serial number |
Test item |
Test standard |
Performance indicator |
|
1 |
Light -resistant color accuracy (5 cycles) |
PV 1303 |
According to DIN EN20105-A02, gray level ≥ 4, color tone changes are not allowed |
|
2 |
thickness |
DIN53370-2006 |
0.45±0.05mm |
|
3 |
Unit area weight |
TL 292A-2006 |
>430 g/m? |
|
4 |
Fracture intensity (vertical) |
DIN53354-1981 |
>250N/5cm |
|
5 |
Fracture intensity (horizontal) |
DIN53354-1981 |
>250N/5cm |
|
6 |
Fracture and extension (vertical) |
DIN53354-1981 |
>200% |
|
7 |
Fracture and extension (horizontal) |
DIN53354-1981 |
>250% |
|
8 |
Friction |
DIN EN ISO105-X12-2001 |
According to DIN20105-A03, with a grayscale level of 5, a middle score of 4.5 is allowed |
|
9 |
High temperature performance（115℃/48h） |
TL52473-2003 |
Components are not allowed to become brittle, nor are obvious or functionally impaired changes in shape, color, and surface allowed. The size shrinkage deformation of the sunshade sheet is less than 3% |
|
10 |
Low temperature performance（-20℃/24h） |
PV3905-2005 |
Cold drop ball test without cracks or ruptures |
|
11 |
Climate -resistant changes (8 cycles) |
PV2005-A-2000 |
The sample has no cracks, no deformation, and no significant changes on the surface. |
|
12 |
Combustion characteristics |
TL 1010-2008 |
≤100mm/min |
|
13 |
Amine emission |
PV3944-2011 |
No special ammonia odor △ a ≤ 2 △ b ≤ 2 |
|
14 |
Amine emits fog |
VW50180-2015 |
G≤2mg |
|
15 |
total carbon |
VW50180-2015 |
EG≤50ugC/g |
|
16 |
formaldehyde |
VW50180-2015 |
Release potential threshold ≤ 10mg/kg |
|
17 |
odor |
VW50180-2015 |
C3≤3.5 |
|
18 |
color difference |
VW50190-2011 |
△L=±0.45 △a=±0.25 △b=±0.25 |
